XPS Foam Board Production Line
XPS Foam Board Production Line

Introduction of XPS foam board production line

1.Focus on the manufacturing and technology research of complete sets of XPS foamed extrusion line
2.In China we master most advanced CO2 foaming technology for XPS extrusion line, can provide turn-key project solution for domestic and overseas customers.

3.Full automatic control of processing, with stable and efficient productions

1469072466132894

Model disctription:

(S - means the 1st stage is single screw extruder, D - means the 1st stage is double screw extruder)

Main extruder

Screw diameter
(mm)

Driving motor(kw)

Extrusion capacity
(kg/h)

Range of product density(mm)

Thickness range of product(mm)

S90/120

90/120

45/37

150-200

28-36

20-50

S135/150

135/150

75/55

300-400

28-36

20-100

S170/200

170/200

200/90

400-600

28-36

20-100

D65/120

65/120

45/37

150-200

28-36

20-50

D75/150

75/150

110/90

300-400

28-36

20-120

D85/200

85/200

132/90

500-700

28-36

20-150

D95/250

95/250

160/132

700-1000

28-36

20-150

Notes: (1st stage screw Recommend to use double-screw)

Advantage of adopting double-screw :compared with single screw used for 1st stage of extruder, the double screw has more capacity, stable working.

Equipment list
1.Material loading and feeding system (Germany brabenda for option)
2.1st stage of parallel
double screw extruder
3.Foam agent injection system (Linde or Lewa for option )

4.Screen exchanger
5.2nd stage of single screw extruder
6.Static mixer
7.Die
8.Calibration unit
9.Haul-off unit
10.Cooling conveying roller
11.Edge cutter
12.Main Cross cutter
13.Electric control system ( ABB, SIEMENS, SCHNEIDER Brand)
Optional list
1.Surface planer and groover
2.Longitudinal groover (longitudinal trimming and shiplap, like SL,TG,RC)
3.Cross groover (cross trimming and shiplap)
4.Cooling and turning rack (vertical cooling tower )
5.Packaging machine
6.Automatic packing machine
7.Recyling machine
